Tiso Turnstile Distributor In Pakistan

With access control the doors may usually use but the speed gates are also being used. The quality speed gates and turnstile manufacturer are Tiso and Iot systems is bringing it into Pakistan.

TISO CENTURION-M

TISO TRIPOD TURNSTILE CENTURION-M FEATURES

Low Noise Operation CENTURION-M

The TISO CENTURION-M is a revolutionary new product that offers whisper quiet, low noise operation. This product has been designed to reduce the sound of running machinery and other equipment in industrial, commercial and residential settings. It features advanced acoustic dampening technology that helps to reduce the sound level of any environment by up to 50%. With this product, you can enjoy a quieter working environment without sacrificing performance or productivity. The TISO CENTURION-M is the perfect solution for businesses looking for a way to reduce noise levels while still providing high quality performance.

TISO TRIPOD TURNSTILE CENTURION-M
TISO TRIPOD TURNSTILE CENTURION-M

Bi-Directional Operation

The TISO CENTURION-M is a bi-directional motorized tripod turnstile with panic/bar drop function. It is designed to provide security and access control for large public spaces, such as airports, stadiums, and other high-traffic areas. The turnstile has a built-in panic button that allows people to quickly exit the area in case of emergency. It also has a bar drop function that automatically drops the arm when it senses an obstruction. This makes it an ideal solution for controlling crowds in busy areas and ensuring safety of people in distress situations.

TISO TRIPOD TURNSTILE CENTURION-M
TISO TRIPOD TURNSTILE CENTURION-M

Integration with Access Control and Biometric systems in CENTURION-M

The TISO CENTURION-M Tripod Turnstile is a cost-effective way to control access to your facility. This turnstile is designed for both indoor and outdoor use. It can be integrated with any type of access control system and ID system, making it a versatile turnstile solution for your business.

TISO TRIPOD TURNSTILE CENTURION-M
TISO TRIPOD TURNSTILE CENTURION-M

Specification

Product Parameters Product Specification
Dimension 1000x793x847
Crossing capacity in free access mode, person/min 60
Crossing capacity in single access mode, person/min 25
Passage Width 600mm
Mechanism Servo-Driven(Triservo-M)
Blocking Mechanism Two electromechanical stop catches (separate locking system)
Emergency Mode(When Power Goes Off Arms Drop when Power Goes Off
Drop Arm function Drop arm function can be activated when power is on Drop arm function activates automatically when power goes off
Available Housing Brushed SS AISI 316 Polished SS AISI 304 Polished SS AISI 316 Powder coated (any RAL up on request)
Voltage AC (100-240)V, 50/60Hz; DC source 12 V
Maximum Power Consumption 55W
Enclosure Rating IP41-54*
MCBF, Cycles 1500000

Downloads

Tiso Tripod Turnstile Centurion-M Datasheet

Features

  • Bi-Directional motorized tripod turnstile with panic/bar drop function
  • Integration with any type of Access Control and ID system
  • Low Power Consumption
  • Wide Range Of Accessories
  • Availability of back up battery connection
  • Complete Supply set as a standard
