Soyal AR-331-H Features

Slim Appearance in Soyal AR-331-H

The AR-331-H is a slim and sleek design that will work well with any modern home. It also has an aesthetically pleasing design that is sure to catch your eye. The AR-331-H is made out of metal, and it has a matte black finish. It also has a shiny black finish on the buttons, making them stand out in contrast to the matte black metal finish.

The Soyal AR-331-H will work with any modern home because of its sleek and slim appearance. It also has an aesthetically pleasing design that is sure to catch your eye. The AR-331-H is made out of metal, and it has a matte black finish. It also has a shiny black finish on the buttons, making them stand out in contrast to the matte black metal finish

Soyal-327-E

Anti-Vandalism in Soyal AR-331-H

The Soyal AR-331-H is a smart access control that can be used for anti-vandalism and anti-theft purposes.

The Soyal AR-331-H is a new model of access control that is designed to combat vandalism and theft. The product features an IP65 rating, which means it is resistant to dust, water and oil. It also features an SD card slot for storing data offline.

soyal-ar331h-features
Soyal AR331H ANTI-VANDALISM

MULTIPLE SECURITY PROTECTION in Soyal AR-331-H

The Soyal AR-331-H is a lock that provides security for your home.
The AR-331-H is a USB smart card reader that provides MiFare and DESFire protection.

The AR-331-H is a USB smart card reader that provides MiFare and DESFire protection. There are two types of cards that the AR-331-H supports: MiFare Classic and DESFire EV1. The AR-331-H has a built in keypad and screen to help the user with their PINs, passwords, or other security measures they may need to enter on the card.

SOYAL-AR331H-MULTIPLE SECURITY PROETCTION
MULTIPLE SECURITY PROETCTION AR331H

Each Controller can set up to 3 master cards in Soyal AR-331-H

The Soyal AR-331-H is a 3D Controller that can be used with the Soyal 3D VR Headset. It has buttons for navigation, interaction, and selection.

The Soyal AR-331-H is a 3D controller that can be used with the Soyal 3D VR Headset. The controller has buttons for navigation, interaction, and selection. The AR-331-H is the perfect companion to the headset as it allows you to navigate your way through virtual worlds without ever taking off your headset.

SOOYAL-331H-EACH-CONTROLLER-CAN-SET-UP-TO-MASTER-CARDS
EACH CONTROLLER CAN SET UP TO MASTER CARD

Soyal Access Control Distributor in Pakistan

Soyal access control distributor is Iot Systems in Pakistan, Iot Systems are the first mover which brings the latest and most secure technologies introduced in Pakistan. An IT Company which has industry-specific expert which have sufficient support from brands that they provide and install




Specification

Product Parameters Product Specification
Frequency 125kHz/ 13.56MHz / Dual Band (125kHz & 13.56MHz)
Standard 125kHz: EM Standard
13.56MHz: ISO14443A, DESFire, Customization(ISO15693, Felica, NFC)
Reading Range 125kHz: 3-7 cm;
13.56MHz: 1.3 cm
Power Consumption 9-24VDC, Less than 5W
Communication Interface RS-485/9600 bps(N,8,1)
Ethernet/td>

None / AR-727CM (Option)
Serial TTL*1 (4800)
Digital Input 1 Egress(R.T.E.) / 1 Door contact
Relay Output Lock Relay,ON/OFF 0.1-600 Sec
Transistor Output Arming LED(for Security trigger signal)/WG Lock/Alarm/Duress
Alarm Time Toggle, 1-600 Sec
User Capacity 3,000(Card/PIN User)/500(FP User and each with 3 templates)
Event Log 1,500
External Reader 1 Wiegand Port
Anti-Pass Back Yes
Lift Control 32 Floors, 3,000 Users
Time Zone 11
Indicator 2LED & 1Beeper
Housing Material PC&Zinc Alloy/PC Frame(By order)
Dimension(mm) 158(L)X55(W)X30(H)
Ingress Protection IP56

Downloads

AR-331-H Datasheet

Features

  • Slim Design Proximity Controller
  • Slim appearance suitable for narrow place and limited area
  • Multiple Security Protection RS-485 Security Encryption (SSC),Mifare/DESFire encryption supported, built-in watchdog to prevent system from hanging
  • Each Controller can set up to 3 masters card
  • 125kHz or 13.56MHz Access Controller Built-in Hardware Watchdog & Real Time Clock Function
  • Multi Operation Mode
  • Silent Operation Mode: Push Button and All Mute
  • Auto Open Time Zone: Built in 2 time zones, with Control Panel up to 63 time zones
  • Access control, lift control, time attendance, payroll, and SCADA: graphic monitoring & remote control function
  • Standalone / Networking / Support Cascade Structure
  • Multi Output: Door lock output (0.1-600 sec. and toggle mode) & alarm output (1-600 sec)
  • Support One and Half Door, and One and Half Door Anti-Passback
  • Auto Relock for Anti-Trailing and Sneaking
