AR-0600M-DB

Description

SOYAL AR-0600M-DB
INDOOR Electronic Magnetic Lock

User Friendly Customizability

Their mode can be set via user requirements.

The Soyal AR-0180M is a user-friendly and customizable magnetic lock that can be installed in any area with an electric power supply. The installation process is simple and the lock can be easily customized to suit the needs of the customer.

The Soyal AR-0180M indoor magnetic lock has a number of features that make it user-friendly. It is easy to install and requires no additional tools to do so. It also has a built-in timer that allows for scheduled locking times which saves power consumption, as well as an alarm system that alerts the user when someone tries to tamper with the door or lock.

User Friendly Customizability
User Friendly Customizability in AR-0600-DB

Works Under Extreme Temperatures

The Soyal AR-0600M-DB is a magnetic door lock that works best in extreme temperatures. The locks are made of stainless steel and are resistant to corrosion.

The Soyal AR-0600M-DB is a magnetic door lock that features a low battery consumption and has an auto-locking system. It also has a high level of resistance to corrosion.

Simple and Easy Design

The design of this door lock is a simple and easy installation.

The Soyal AR-0600M-DB magnetic door lock is an excellent, affordable option for securing your home. The design of this door lock is a simple and easy installation. This magnetic door lock has a sleek finish and can be mounted on the inside or outside of your front or back doors.

This magnetic door lock is perfect for any home as it can be mounted on the inside or outside of your front or back doors.

Durability Of AR-0600M-DB

A magnetic door lock is used in a door or other opening that is not closed by a conventional key, latch, or bolt.

Magnetic door locks are also called electromagnetic locks. They use magnets to open and close the lock. The magnetic force between two moving magnets is what enables it to work. When the two magnets are far apart, they don’t have any effect on each other and the lock remains closed. But when the two magnets are brought close together, their magnetic fields interact and push against each other with enough force to open the lock.

The Soyal AR-0600M-DB is an example of a magnetic door lock. It has an IK10 rating which means it can withstand attacks from tools like hammers and drills for up to 10 minutes before failing to resist forced entry.

Soyal Access Control Distributor in Pakistan

Soyal access control distributor is Iot Systems in Pakistan, Iot Systems are the first mover which brings the latest and most secure technologies introduced in Pakistan. An IT Company which has industry-specific experts which has sufficient support from brands that they provide and install




Specification

Product Parameters Product Specification
Operating Voltage 12-24 VDC
Current Draw 12 VDC – 500 mA
24VDC–250 mA
Lock Type Lock Housing: Allumunium Alloy, Armature Plate: Pure Iron, Bracket: Allumunium Alloy
Holding Force(kg) 270
Solenoid Test Over 500,000 times
Temperature Lock Surface: ≦ ambient temperature ± 20°C
Operating: -10°C ~ +55°C
Humidity 0~95% non-condensing
Dimension(mm) Magnet: 47(H)X502(W)X25(D)
Armature Plate: 185(H)X38(W) X12(D)* 2units

Electronic Magnetic Lock Net Weight (kg) approx. 3.1kg
Door Monitoring Output YES
LED Indicator YES

Downloads

AR-0600M-DBB Datasheet

Features

  • Provides 4 sets of delay time and easily upgrade standard magnetic lock to magnetic lock with delay time
  • Delay time setting method: set by DIP switch
    Delay time: 0.1, 3, 6, 9 seconds
